Resistance 5.2 ohms 20 ohms
Coil for Liquid Injection Solenoid (LIS) – MAX Only
Voltage 12 Vdc
Current 1.2 amps
Resistance 10.0 ohms
Coil for Heat Pilot Solenoid (PS5) - Truck Engine Coolant Heat Option Only
Voltage 12 Vdc
Current 1.5 amps
Resistance 8.0 ohms
Drain Line Heaters (Each) - MAX Only
Voltage 12 Vdc
Current 0.9 amps ± 5% at 68 F (20 C)
Resistance 13.8 ohms ± 5% at 68 F (20 C)
Battery Relay (BATR)
Type Single Pole Single Throw
(SPST)
Contacts Terminals 30 to 87 Normally Open (NO)
Coil Resistance Terminals 85 to 86 90 ohms
Electric Standby Power Relay (STDR)
Type Single Pole Single Throw
(SPST)
Contacts Terminals 30 to 87 Normally Open (NO)
Coil Resistance Terminals 85 to 86 90 ohms
Capacitors
Running Capacitor (CR) (1ph units) 60 μF 475 Vac
Compressor Motor Contactor (CMC)
Contacts Normally Open
Coil Voltage 12 Vdc
Coil Current 0.25 amps
Coil Resistance 48 ohms
