Transformer
Power 700 VA
Frequency 50/60 Hz
Primary Inputs 0–230–400 Vac
Secondary Nominal Voltage 2 x 11.7 Vac (30.4 amps)
AC Electric Compressor Motors and Overload Relays
Voltage/Phase/Frequency
RPM
Full Load (amps) Overload Relay Setting
(amps)
230/1ph 50/60Hz 3000 (50 Hz) / 3600 (60 Hz) 20 18
230/3ph 50/60Hz 3000 (50 Hz) / 3600 (60 Hz) 16 16
400/3ph 50/60 3000 (50 Hz) / 3600 (60 Hz) 9 10
Electric Standby Power Supply Requirements
Power Cord Length
Power Cord Size (AWG)
Voltage Phase
Hz
Power Supply Circuit Breaker 25 ft 50 ft 75 ft
230 Vac 1 50/60 30 amp 10 8 8
230 Vac 3 50/60 30 amp 10 8 8
