Electrical Requirements
1. Always check the unit nameplate for the MCA and MOP requirements.
2. The fuse is located on the main electrical board.
3. A dedicated indoor unit disconnect switch and power supply circuit may need to be installed
if local codes or jurisdictions require it. Otherwise, the indoor unit is powered directly from the
outdoor unit.
4. Install a separate disconnect at the outdoor unit. The power supply, wiring and grounding of
equipment must comply with National, State and/or local codes. The power supply must match
with the equipment nameplate specification.
5. Improperly installed and grounded field wiring poses fire and electrocution hazards. For
high voltage connections, flexible electrical conduit is recommended whenever vibration
transmission may create a noise problem within the structure. To avoid these hazards you
MUST follow requirements for field wiring installation and grounding as described in the
National Electrical Codes (NEC) and your State and/or local electrical codes. All field wiring
MUST be performed by qualified personnel. Failure to follow these requirements could result in
death or serious injury.
6. The wiring, including the ground wire, between the indoor and outdoor units should be at least
14 AWG, 600 volt rated, stranded wire, with an absolute maximum length of 230 ft. (70m).
Shorter lengths result in more robust communication between the indoor and outdoor unit.
Please select an appropriate length for the installation conditions. The wires cannot be cut and
spliced together.
7. For the wired controller: The communication distance between the main board and the wired
controller can be up to 65 ft. (19.8m). The standard distance is 25 ft. (7.6m).
Heat Pump Models
Cooling Models
M4THS1509
M4TCS1509
M4THS1512
M4TCS1512
M4THS1518
M4TCS1518
M4THS1524
M4TCS1524
Power Supply 208/230V, 60Hz, 1phase
Electrical Connections
CAUTION
Improper operation may lead to personal injury or property damage.
Size the power supply wiring according to the NEC, local code and the MCA indicated on the unit
nameplate.
88-M4MHW15-1D-EN 27
Installer's Guide

Trane 15 Series Specifications

General

Refrigerant	R-410A
HSPF	Not Applicable
SEER Rating	Up to 16.0
Cooling Capacity	1.5 to 5 tons
Sound Level	72 dB
Stages	Single-Stage
Warranty	10 year limited warranty on compressor
