Trane 2MCC05-C User Manual

16 MS-SVN056C-EN
Cassette Unit Installation
sponge seal
(insulation)
body
ceiling
panel
foam rubber
on panel 1
outgoing air
fan
foam rubber on panel 2
4
-
mm6
foam rubber on the outlet
Leak
Ceiling
Contamination
Condensation leaking
Loosen top screw
Adjust lower screw
Spacing forbidden
Tapping screw on
corner cover panel
Slide all four bars in the
corresponding channel
when installing the cover panel
