MS-SVN056C-EN 61
Wiring Diagrams
Outdoor Unit - Cooling Only - 4TTK05-D (12K) - 1 Phase
TO INDOOR UNIT
RED
RED
BLUE
COMP
C
R(M)
S
BLUE
1 2(N)
OUTDOOR UNIT
BK
BLACK
CAPACITOR
FAN
MOTOR
BLACK
RED
OVERLOAD
RELAY
(INTERNAL/
EXTERNAL
DEPENDING
ON MODELS)
RED
This symbol indicates
the element is optional ,
the actual shape shall
be prevail.
CAPACITOR
Y/G
Pressure
switch
2
2
T4/T3
Pressure
switch port
YELLOW
BLUE
BLACK
BROWN
RED
