Trane 3H/2C User Manual

BAS-SVX36C-EN 7
Introduction
Dimensions
Figure 1 and Figure 2 provide dimensions for each type of thermostat.The two non-programmable
thermostats have the same dimensions; the programmable thermostat has slightly different
dimensions.
Figure 1. ProgrammableThermostat Dimensions
3.25 in.
(83 mm)
1.08 in.
(27.5 mm)
4.7 in.
(119 mm)
0.3 in.
(8 mm)
Typ.P Radius 0.08 in. (2 mm)
3.4 in.
(86 mm)
Note: Drawing not to scale. Dimensions within ± 0.02 in. (± 0.5 mm)
Typ. Radius
0.08 in.
(2 mm)
