Installation
On unit sizes 125-155-175-200-250-
265-290-340, the return air sensor of the
economizer needs to be placed into to
return air section of the ERM.
Place return air temperature sensors in the
air return section of the ERM as indicated in
Figure 9.
ERW
125-155-175-200-250-265-290-340
PHE
125-155-175-200-250-265-290-340
Rooftop unit
Rooftop unit
RAS
RAS
Figure 9 -
