Trane 4MXW3812A1 - Unit Dimensions

The dimensions in these drawings
are rounded according to standard
measurement.
Indoor Unit Dimensions
9K-12K Indoor Units
Unit:inch
4 5/8
27 7 5/8
5 1/2
7 1/2
1 1/2
Φ2 1/4
Φ2 1/4
39 1/4 8 7/8
11 7/8
18K-24K Indoor Units
Unit:inch
43 3/8
12 7/8
9 13/16
8 9/16
26 15/16
7 7/8
1 11/16
6 1/16
3 1/8
Φ2 3/4Φ2 3/4
35
38 Series Mini-Split
