Trane 4TXM2324BF300AA - Page 67

65
TRANE Model 4TXM2318BF300AA 4TXM2324BF300AA
Outdoor noise level (sound pressure) dB(A) 52 53
Throttle type EEV EEV
Outdoor unit
Dimension(W×D×H) mm 890×340×700 890×340×700
Packing(W×D×H) mm 998×443×770 998×443×770
Net/Gross weight kg 51/55 54/58
Refrigerant type/
Quantity
Type R410a R410a
Charged volume kg 1.9 1.9
Design pressure MPa 4.15 4.15
Refrigerant
piping
Liquid side/ Gas side mm(inch) 3×Φ6.35/3×Φ9.52 3×Φ6.35/3×Φ9.52
Max. pipe length m 30 50
Max. di󰀨erence in level m 15 15
Ambient
temperature
Cooling °C -10~46 -10~46
Heating °C
-15~24 -15~24
Qty’per 20’ /40’ /40'HQ
Outdoor
unit
90/180/180 90/180/180
