Trane 4TXM2324BF300AA - Page 71

69
TRANE Model 4TXM2342BF500AA
Outdoor unit
Dimension(W×D×H) mm 1,008×447×830
Packing(W×D×H) mm 1,130×490×1,000
Net/Gross weight kg 90/101
Refrigerant type/
Quantity
Type R410a
Charged volume kg 3.2
Design pressure MPa 4.15
Refrigerant
piping
Liquid side/ Gas side mm(inch) 5×Φ6.35/3×Φ9.52+2×Φ12.7
Max. pipe length m 80
Max. di󰀨erence in level m 15
Ambient
temperature
Cooling °C -10~46
Heating °C
-15~24
Qty’per 20’ /40’ /40'HQ Outdoor unit 48/96/96
