Trane 4YCL4024B1055A - Figures & Tables

18
Top View
24 9/10
13 1/2
16
12
13 3/10
13 1/2
16
12
CG
A
47 1/2
3/4" NPT Female
Drain Connector
B
DOWNFLOW
SUPPLY DUCT
OPENING
DOWNFLOW
RETURN DUCT
OPENING
23 1/2
Side View
BLOWER
ACCESS
ELECTRIC
SUPPLY ENTRY
(1.25 DIA.)
LOW
VOLTAG E
ENTRY (.88 DIA.)
GAS SUPPLY
ENTRY (1.63 DIA.)
27.90
7.29
4.07
47.42
Back View
12.45
12.45
4.0
D
8.75
Horizontal
Supply Duct
Opening
Horizontal
Return Duct
Opening
4.0
1.75
9.75 24.75
16.0
Condensing
Coil
13.5
16.0
16.0
C
13.5
Figure 10. Unit Dimensions
MODEL
NUMBER
UNIT
WEIGHT
SHIPPING
WEIGHT
CENTER OF GRAVITY HEIGHT IN INCHES (C)
A B WITH BASE RAILS WITHOUT BASE RAILS
4YCL4024B1055A 390 406 26.5 26.5 35.0 31.3
4YCL4030B1070A 390 406 26.0 26.5 35.0 31.3
4YCL4036B1070A 390 406 26.5 26.5 35.0 31.3
4YCL4042B1100A 438 455 27 26.5 39.0 35.3
4YCL4048B1100A 459 476 27 26.5 43.0 39.3
4YCL4060B1100A 490 507 27 27.5 47.0 43.3
Table 5. Center of Gravity & Unit Shipping Weights
FIGURES & TABLES
