Trane 80 User Manual

3Pub. No. 22-1682-05-0802 (EN)
Contents
Feature Summary
Features and Benefits
Standard Equipment
Optional Equipment
General Data
TUY060R9V3V
TUY080R9V3V
TUY100R9V4V
TUY120R9V5V
Performance Data
Electrical Data
Field Wiring
Dimensions
2
4
6
7
11
12
15

Trane 80 Specifications

General

Efficiency	80% AFUE
Heating Stages	Single-Stage
Ignition System	Hot Surface Ignition
Fuel Type	Natural Gas or Propane
Heat Exchanger Material	Aluminized Steel
Heating Capacity	40, 000 - 120, 000 BTU/h (varies by model)
Warranty	Limited Lifetime on Heat Exchanger
