Trane A4AH4E36A1C30A User Manual

18-GF16D1-1A-EN
27
Figure 22. A4AH4E36, A4AH4E42 — Front view
Snap
Tab
Feature
180°
Remove 2 screws
and water diverter
bracket
Top Baffle Assembly
Figure 23. A4AH4E36, A4AH4E42 — Front view
Snap
Tab
Feature
Replace 2 screws
and water diverter
bracket
Top Baffle Assembly
Figure 24. A4AH4E36, A4AH4E42 — Rear view
Snap
Tab
Feature
Top Baffle Assembly
Remove 2 screws
and water diverter
bracket
Figure 25. A4AH4E36, A4AH4E42 — Rear view
Snap
Tab
Feature
Remove 2 screws
and water diverter
bracket
Top Baffle Assembly
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss

Trane A4AH4E36A1C30A Specifications

General

Brand	Trane
Model	A4AH4E36A1C30A
Category	Air Handlers
Language	English
