28
18-GF16D1-1A-EN
Figure 26. A4AH4E48, A4AH4E60 — Front view
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
180°
Top Baffle Assembly
Figure 27. AA4AH4E48, A4AH4E60 — Front view
Replace 2 screws
and water diverter
bracket
Top Baffle Assembly
Figure 28. A4AH4E48, A4AH4E60 — Rear view
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Figure 29. A4AH4E48, A4AH4E60 — Rear view
Replace 2 screws
and water diverter
bracket
Snap Tab
Feature
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
