Trane A4AH4E48B1C30A - Features

18-GF16D1-1A-EN
5
Features
Table 1. Standard Features
• MULTI-POSITION UPFLOW, DOWNFLOW, HORIZONTAL LEFT
AND HORIZONTAL RIGHT
• GALVANIZED STEEL EXTERIOR WITH FULLY INSULATED
CABINET THAT MEETS R4.2 VALUE
• STURDY POLYCARBONATE DRAIN PANS
– Factory installed drain pans; upflow and horizontal left
as shipped
• 208/230 VAC OPERATION
• MULTI-SPEED DIRECT DRIVE BLOWERS
• FACTORY INSTALLED R-410A THERMAL EXPANSION VALVE
• ALL ALUMINUM COIL
• BOTTOM RETURN
• MEETS THE MINIMUM LEAKAGE REQUIREMENTS FOR THE
FLORIDA AND CALIFORNIA BUILDING CODES
Table 2. Optional Accessories
• 4,5,8,10,15, 20 and 25 KW SINGLE PHASE ELECTRIC
HEATERS
– Circuit breakers available on all single phase 4, 5, 8, 10,
15, 20 and 25 KW heaters
– Lug terminals available on all single phase 4, 5, 8, and
10 KW heaters
• 10 and 15 KW THREE PHASE ELECTRIC HEATERS
– Heaters available with lug terminals
• SINGLE POINT POWER ENTRY KIT (for 15 and 20 KW
Heaters)
• SUPPLY DUCT FLANGE KIT
• DOWNFLOW SUB-BASE KITS - TAYBASE185, TAYBASE235
• R-22 CONVERSION KITS — BAYATXV1836B,
BAYATXV4248B, BAYATXV6161B
• SLIM FIT FILTER BOX KIT — BAYSF1185AAA,
BAYSF1235AAA
