Table 22. Air Flow Performance
A4AH5V48A1C30A, A4AH5V60A1C30A HEATING AIRFLOW PERFORMANCE, NO FILTER, NO HEATER
OUTDOOR
UNIT SIZE
(TONS)
SPEED
SETTING
AIRFLOW
SETTING
DIP SWITCH SETTING
AIRFLOW
POWER
EXTERNAL STATIC PRESSURE
SW1 SW2 SW3 SW4 0.1 0.3 0.5 0.7 0.9
3
LOW
360 CFM/
ton
ON ON OFF ON
CFM
Watts
1097
112
1094
160
1086
216
1092
271
1099
326
NORMAL
400 CFM/
ton
ON ON OFF OFF
CFM
Watts
1215
142
1216
196
1210
255
1211
314
1215
369
HIGH
440 CFM/
ton
ON ON ON OFF
CFM
Watts
1333
178
1338
238
1333
300
1331
365
1332
428
3.5
LOW
348 CFM/
ton
OFF ON OFF ON
CFM
Watts
1232
147
1234
202
1228
261
1229
322
1233
377
NORMAL
387 CFM/
ton
OFF ON OFF OFF
CFM
Watts
1366
189
1373
252
1369
314
1366
381
1365
447
HIGH
426 CFM/
ton
OFF ON ON OFF
CFM
Watts
1500
238
1511
311
1510
377
1502
449
1498
529
4
LOW
338 CFM/
ton
ON OFF OFF ON
CFM
Watts
1364
188
1370
251
1366
313
1363
379
1363
446
NORMAL
375 CFM/
ton
ON OFF OFF OFF
CFM
Watts
1509
241
1520
315
1519
382
1511
453
1506
535
HIGH
413 CFM/
ton
ON OFF ON OFF
CFM
Watts
1659
305
1674
395
1676
466
1662
541
1654
632
5
LOW
326 CFM/
ton
OFF OFF OFF ON
CFM
Watts
1637
295
1652
383
1653
453
1641
528
1632
618
NORMAL
(a)
362 CFM/
ton
OFF OFF OFF OFF
CFM
Watts
1814
381
1834
493
1839
570
1820
645
1807
730
HIGH
398 CFM/
ton
OFF OFF ON OFF
CFM
Watts
1990
481
2017
625
2025
713
2000
779
1982
826
(a)
Factory Default Setting
Table 23. Electrical Data
A4AH5V48A1C30A, A4AH5V60A1C30A HEATER DATA
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 6.8 * 9 15 6.8 * 9 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 29 30 2.88 9800 13.8 26 30
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.80 16400 20.0 34 35 3.60 12300 17.3 30 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 49 50 5.76 19700 27.7 43 45
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1517BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1517BRK
Circuit 2
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYHTR1523BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 59 60 7.20 24600 34.6 52 60
BAYHTR1523BRK
Circuit 2
9.60 32800 40.0 50 50 7.20 24600 34.6 43 45
BAYHTR1525BRK
Circuit 1
(a)
4/1
6.00 20500 25.0 40 40 4.50 15400 21.6 36 40
BAYHTR1525BRK
Circuit 2
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR1525BRK
Circuit 3
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR1525BRK
Circuit 4
6.00 20500 25.0 31 35 4.50 15400 21.6 27 30
BAYHTR3510LUG
1/3
9.60 32800 23.1 36 40 7.20 24600 20.0 33 35
BAYHTR3517LUG
1/3
14.40 49100 34.6 51 60 10.80 36900 30.0 45 45
* = Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
PPeerrffoorrmmaannccee aanndd EElleeccttrriiccaall DDaattaa
