Table 15. Air Flow Performance (continued)
A4AH5V30A1B30A COOLING AIRFLOW PERFORMANCE, WET COIL, NO FILTER, NO HEATER
3
LOW
310 CFM/
ton
OFF OFF OFF ON
CFM
Watts
913
119
947
172
962
233
938
297
883
364
NORMAL
(a)
330 CFM/
ton
OFF OFF OFF OFF
CFM
Watts
967
138
1004
194
1022
258
1000
326
947
397
(a)
Factory Default Setting
Table 16. Air Flow Performance
A4AH5V30A1B30A HEATING AIRFLOW PERFORMANCE, NO FILTER, NO HEATER
OUTDOOR
UNIT SIZE
(TONS)
SPEED
SETTING
AIRFLOW
SETTING
DIP SWITCH SETTING
AIRFLOW
POWER
EXTERNAL STATIC PRESSURE
SW1 SW2 SW3 SW4 0.1 0.3 0.5 0.7 0.9
1.5
LOW
394 CFM/
ton
ON ON OFF ON
CFM
Watts
599
58
571
88
539
117
502
146
462
175
NORMAL
448 CFM/
ton
ON ON OFF OFF
CFM
Watts
680
72
665
109
641
145
610
178
572
209
HIGH
493 CFM/
ton
ON ON ON OFF
CFM
Watts
748
89
746
118
682
163
545
208
326
240
2
LOW
393 CFM/
ton
OFF ON OFF ON
CFM
Watts
785
97
790
128
773
175
735
223
674
253
NORMAL
446 CFM/
ton
OFF ON OFF OFF
CFM
Watts
904
131
902
179
912
219
894
253
809
281
HIGH
491 CFM/
ton
OFF ON ON OFF
CFM
Watts
980
167
972
216
990
268
974
308
863
324
2.5
LOW
350 CFM/
ton
ON OFF OFF ON
CFM
Watts
866
125
870
162
866
215
833
263
750
286
NORMAL
398 CFM/
ton
ON OFF OFF OFF
CFM
Watts
995
171
988
222
1005
271
986
309
872
325
HIGH
437 CFM/
ton
ON OFF ON OFF
CFM
Watts
1099
220
1086
274
1098
328
1065
362
918
353
3
LOW
325 CFM/
ton
OFF OFF OFF ON
CFM
Watts
953
133
990
188
1007
251
985
318
931
389
NORMAL
(a)
346 CFM/
ton
OFF OFF OFF OFF
CFM
Watts
1010
154
1049
212
1066
279
1047
350
1000
426
(a)
Factory Default Setting
Table 17. Electrical Data
A4AH5V30A1B30A HEATER DATA
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 4.3 * 5 15 4.3 * 5 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.84 13100 16.0 25 25 2.88 9800 13.8 23 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
BAYHTR1517BRK
Circuit 1
(a)
2/1
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
BAYHTR1517BRK
Circuit 2
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYHTR3510LUG
1/3
9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
BAYHTR3517LUG
1/3
14.40 49100 34.6 48 50 10.80 36900 30.0 42 45
* = Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
