30
18-GF15D1-1B-EN
Figure 20. A4AH5E43A1C30AA, A4AH5V36A1C30AA, A4AH5V42A1C30AA
Snap Tab
Feature
Top Baffle
Assembly
Replace 2 screws
and water diverter
bracket
Remove 2 screws
and water diverter
bracket
Snap Tab
Feature
Top Baffle
Assembly
Figure 21. A4AH5E49A1C30AA, A4AH5E61A1C30AA, A4AH5V48A1C30AA, A4AH5V60A1C30AA
Snap Tab
Feature
Top Baffle
Assembly
Snap Tab
Feature
Top Baffle
Assembly
Remove 2 screws
and water diverter
bracket
Replace 2 screws
and water diverte
r
bracket
CCooiill CCoonnvveerrssiioonn IInnssttrruuccttiioonnss
