Trane AM7A0C48H41SA Series User Manual

TAM717
kW BTUH kW BTUH
No Heater 0 - - 3.0** 4 15 - - 3.0** 4 15
BAYEVAC05++1 1 4.80 16400 20.0 29 30 3.60 12300 17.3 25 25
BAYEVAC08++1 1 7.68 26200 32.0 44 45 5.76 19700 27.7 38 40
BAYEVAC10++1 1 9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
BAYEVAC10LG3 1-3 PH 9.60 32800 23.1 32 35 7.20 24600 20.0 28 30
BAYEVBC15LG3 1-3 PH 14.40 42000 34.6 47 50 10.80 36900 30.0 41 45
9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
9.60 32800 40.0 54 60 7.20 24600 34.6 47 50
9.60 32800 40.0 50 50 7.20 24600 34.6 43 45
Note: * May be "A" or "T"
Note: ** Motor Amps
1 MCA and MOP for circuit 1 contains the motor amps
Heater Attribute Data
*AM7A0C42H31SA
Heater Model No.
No. of
Circuits
240 Volt 208 Volt
Capacity Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
BAYEVBC15BK1 - Circuit 1 1
BAYEVBC15BK1 - Circuit 2
BAYEVBC20BK1 - Circuit 1 1
BAYEVBC20BK1 - Circuit 2
2
2
kW BTUH kW BTUH
No Heater 0 - - 4.2** 5 15 - - 4.2** 5 15
BAYEVAC05++1 1 4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYEVAC08++1 1 7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYEVAC10++1 1 9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
BAYEVAC10LG3 1-3 PH 9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
BAYEVBC15LG3 1-3 PH 14.40 42000 34.6 48 50 10.80 36900 30.0 42 45
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
9.60 32800 40.0 50 50 7.20 24600 34.6 43 45
9.60 32800 40.0 55 60 7.20 24600 34.6 49 50
9.60 32800 40.0 50 50 7.20 24600 34.6 43 45
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
BAYEVCC25BK1 - Circuit 1 1
BAYEVCC25BK1 - Circuit 2
BAYEVCC25BK1 - Circuit 3
Note: * May be "A" or "T"
Note: ** Motor Amps
1 MCA and MOP for circuit 1 contains the motor amps
Heater Attribute Data
*AM7A0C48H41SA
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
BAYEVBC15BK1 - Circuit 1 1
BAYEVBC15BK1 - Circuit 2
BAYEVBC20BK1 - Circuit 1 1
BAYEVBC20BK1 - Circuit 2
Heater Model No.
No. of
Circuits
240 Volt 208 Volt
Capacity Heater
Amps per
Circuit
2
2
3
