Table 5. Unit wiring with electric heat (single point connection) - 50Hz
Tons
Unit Model
Number
Heater Model
Number
Heater kW
Rating
Control
Stages
Standard Indoor
Motor
Oversized Indoor
Motor
MCA
Max Fuse
Size or
Max
Circuit
Breaker
MCA
Max Fuse
Size or
Max
Circuit
Breaker
380-415 Volts Three Phase
15 EBC180AD
BAYHTFAK18AA 18 2 42 50 42 50
BAYHTFAK36AA 36 2 54 60 54 60
BAYHTFAK54AA 54 2 78 80 78 80
17½ EBC210AD
BAYHTFAK36AA 36 2 54 70 56 70
BAYHTFAK54AA 54 2 78 80 80 80
BAYHTFAK72AA 72 2 82 100 84 100
20 EBC240AD
BAYHTFBK36AA 36 2 61 80 66 80
BAYHTFBK54AA 54 2 80 80 86 90
BAYHTFBK72AA 72 2 84 100 90 100
25 EBC300AD
BAYHTFBK36AA 36 2 61 80 66 80
BAYHTFBK54AA 54 2 80 80 86 90
BAYHTFBK72AA 72 2 84 100 90 100
Note: Max fuse size or max circuit breaker values do not include power exhaust accessory.
