Table 4. Unit wiring with electric heat (single point connection) - 60Hz (continued)
Tons
Unit Model
Number
Heater Model
Number
Heater kW
Rating
Control
Stages
Standard Indoor
Motor
Oversized Indoor
Motor
MCA
Max Fuse
Size or
Max
Circuit
Breaker
MCA
Max Fuse
Size or
Max
Circuit
Breaker
20 EBC240AK
BAYHTFDK36A 24.6 2 56 70 59 80
BAYHTFDK54A 37 2 62 70 65 80
BAYHTFDK72A 49 2 79 90 82 90
25 EBC300AK
BAYHTFDK36A 24.6 2 68 90 - -
BAYHTFDK54A 37 2 68 90 - -
BAYHTFDK72A 49 2 82 90 - -
Note: Max fuse size or max circuit breaker values do not include power exhaust accessory.
(a)
Unit will operate reliably at 400VAC.
