10
ACC-SVN150F-EN
Table 4. Unit wiring with electric heat (single point connection) - 60Hz (continued)
Tons
Unit Model
Number
Heater Model
Number
Heater kW
Rating
Control
Stages
Standard Indoor
Motor
Oversized Indoor
Motor
MCA
Max Fuse
Size or
Max
Circuit
Breaker
MCA
Max Fuse
Size or
Max
Circuit
Breaker
25 EBC300A3
BAYHTFD336A
27/36
2
126/130 175/175 133/140 175/175
BAYHTFD354A
40.5/54
2
135/152 175/175 144/161 175/175
BAYHTFD372A
54/72
2
172/196 200/225 182/205 200/225
460 Volts Three Phase
15 EBC180A4
BAYHTFC418A 18 1 35 45 36 45
BAYHTFC436A 36 2 60 70 62 70
BAYHTFC454A 54 2 71 80 73 80
17½ EBC210A4
BAYHTFC436A 36 2 62 70 66 70
BAYHTFC454A 54 2 73 80 76 90
BAYHTFC472A 72 2 95 110 98 110
20 EBC240A4
BAYHTFD436A 36 2 62 70 66 70
BAYHTFD454A 54 2 73 80 76 90
BAYHTFD472A 72 2 95 110 98 110
25 EBC300A4
BAYHTFD436A 36 2 66 70 70 70
BAYHTFD454A 54 2 76 90 81 90
BAYHTFD472A 72 2 98 110 102 110
575 Volts Three Phase
15 EBC180AW
BAYHTFCW18A 18 1 28 35 29 35
BAYHTFCW36A 36 2 48 50 50 50
BAYHTFCW54A 54 2 56 60 58 70
17½ EBC210AW
BAYHTFCW36A 36 2 50 50 52 60
BAYHTFCW54A 54 2 58 70 61 70
BAYHTFCW72A 72 2 76 90 78 90
20 EBC240AW
BAYHTFDW36A 36 2 50 50 52 60
BAYHTFDW54A 54 2 58 70 61 70
BAYHTFDW72A 72 2 76 90 78 90
25 EBC300AW
BAYHTFDW36A 36 2 52 60 56 60
BAYHTFDW54A 54 2 61 70 65 70
BAYHTFDW72A 72 2 78 90 82 90
380 Volts Three Phase
(a)
15 EBC180AK
BAYHTFCK18A 12.3 1 43 50 - -
BAYHTFCK36A 24.6 2 53 60 - -
BAYHTFCK54A 37 2 62 70 - -
17½ EBC210AK
BAYHTFCK36A 24.6 2 53 60 57 60
BAYHTFCK54A 37 2 62 70 65 70
BAYHTFCK72A 49 2 79 90 82 90
IInnssttaallllaattiioonn
