Trane BAYVALV001 - Page 5

ACC-SVN213B-EN
5
Figure 1. Service valve kit shipping list
1 OR 2
1
3 OR 4
3
9
6
7
5
10
8
Table 2. Service valve kit shipping list
Assembly
Number
Description
1 Suction Valve; Ball
2 Suction Valve; Ball (dual circuit kits only)
3 Liquid Valve; Ball
4
Liquid Valve; Ball (dual circuit kits only)
5 Screw; #10-16 X .50 Sh Met
6 Literature; Installation Guide, Service Valve
7 Envelope-screw
8 Cellulose
9 Package; Carton
10 Label
