Table 3. Dimensional data for CVHE, CVHF and CVHG CenTraVac chillers
Model NTON Shell Size
Comp
Size
USID
USTR
UATR
UPIR
UXL
USID
USTR
UATR
UPIR
UXL
AFDE UAFD
405–608A 900–1210A
Y1 Y2 Y1 Y2 AD Y1 Y2 AD
CVHE
190–270 032 320 79.8
N/A
49.1
N/A
94.9 64.2
N/A N/A N/A N/A
230–320 050 320 94.1
N/A
57.5
N/A
101.2 64.6
N/A N/A N/A N/A
300–420 050 500 92.5
N/A
55.9
N/A
101.2 64.6
N/A N/A N/A N/A
360–500 080 500
(a) (a) (a) (a)
110.6 77.0
N/A N/A N/A N/A
300–450
050/080
500
(a) (a) (a) (a)
111.5 70.63
N/A N/A N/A N/A
CVHF
350–570
050 480 92.7
N/A
56.1
N/A
101.2 64.6
N/A N/A N/A N/A
050/080
480
(a) (a) (a) (a)
111.5 70.63
N/A N/A N/A N/A
080 480
(a) (a) (a) (a)
110.6 77.0
N/A N/A N/A N/A
620–870
080 870
(a) (a) (a) (a)
125.8 92.2 7.0 133.3 99.8 4.8
080/142
870
(a) (a) (a) (a)
140.0 81.75
N/A
147.0 88.8 5.8
142 870
(a) (a) (a) (a)
139.9 77.5
N/A
144.0 91.0 4.6
650–910
080 910
(a) (a) (a) (a)
119.3 85.7
N/A
126.8 93.3 4.8
080/142
910
(a) (a) (a) (a)
132.7 75.33
N/A
146.2 88.8 5.8
142 910
(a) (a) (a) (a)
130.4 77.5
N/A
144.0 91.0 4.6
1070–1300
080/142
1300
(a) (a) (a) (a)
140.0 81.75
N/A
147.0 88.8 6.3
142 1300
(a) (a) (a) (a)
139.9 77.5
N/A
146.0 91.0 4.6
142/210
1300
(a) (a) (a) (a)
147.9 83.6 3.5 154.9 90.6 5.6
210 1300
(a) (a) (a) (a)
N/A N/A N/A
152.4 95.9 3.9
250 1300 140.7
(b)
80.2
(a)
N/A N/A N/A
160.0 99.5 3.1
1470–1720
142/210
1720
(a) (a) (a) (a)
N/A N/A N/A
155.0 90.7 5.6
210 1720
(a) (a) (a) (a)
N/A N/A N/A
152.4 95.9 3.9
250 1720 140.7
(a)
80.2
(a)
N/A N/A N/A
160.0 99.5 3.1
CVHG
480–565
050 565 93.3
N/A
56.6
N/A N/A N/A N/A N/A N/A N/A
080 565
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
050/080
565
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
670–780
080 780
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
080/142
780
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
142 780
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
920–1067
080/142
920
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
142 920
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
142/210
920
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
210 920
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
1100
080/142
1100
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
142 1100
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
142/210
1100
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
210 1100
(a) (a) (a) (a)
N/A N/A N/A N/A N/A N/A
Notes:
1. Refer to Table 5, p. 13.
2. All dimensions are in inches (±0.5 inch).
(a)
When indicated, see Note 1 (above).
(b)
Does not extend beyond the main unit control panel.
See Table 1, p. 6 through for dimensional data
regarding the following figure.
DDiimmeennssiioonnss aanndd WWeeiigghhttss
