Trane CGAD020C - Fig. 23 - Unit Dimensions - CGAD 150 C; Fig. 24 - Top View of Fans; NOTES

28 CG-PRC002A-EN
CGAD 150C
Dimensional
Data
NOTES:
1 - FIXING POINTS FOR VIBRATION INSULATORS (6 X.11,5-mm DIAM HOLES)
2 - VIBRATION INSULATORS ARE NOT SUPPLIED WITH THE EQUIPMENT.
3 - UNITS NOT SPECIFIED: mm
Fig. 23 - Unit Dimensions - CGAD 150C
Fig. 24 - Top View of Fans
