Table 24. Tracer™ TU: Unit Status view: Motor
Expanding section
Motor Winding Temp #1 F/C
Motor Winding Temp #2 F/C
Motor Winding Temp #3 F/C
Table 25. Tracer™ TU: Unit Status view: AF Expanding
section
AFD DC Bus Voltage Vdc
AFD Last Diagnostic Code (decimal) number
AFD Output Power KW
AFD Transistor Temp F/C
Boundary Pressure
Coefficient None
Fre
quency Hz
Frequency Command Hz
IGV and AF Control
Re-optimization Time Remaining Hrs/Mins
Speed RPM
Table 26. Tracer™ TU: Service Setpoints view:
Adjustable Frequency Drive Setpoints section
Description Min Max
Factory
Default Units
AF Control N/A N/A (Auto, Fixed)
Auto
N/A
Re-Optimization Sensitivity 0 100 20% Percent
Note: Use only drive parameter sheet settings; other settings may affect
chi
ller reliability
Note: AF Re-optimization Se
nsitivity - Every 30 minutes the optimizing
algorithm compares the current value of the inlet guide vane position
to the value that was stored after the last re-optimization. If the
difference is greater than the AF Re optimization Sensitivity setting,
re-optimization occurs. This value is adjustable from 0 to 100%,
where 0 would guarantee re-optimization every 30 minutes and
100
% would gu
arantee no re-optimization.
Table 27. Tracer™ TU: Field Startup view: Adjustable
Frequency Drive section
Description Min Max
Factory
Default Units
Maximum Frequency 38 60 60 Hertz (Hz)
Minimum Frequency 38 60 38 Hertz (Hz)
AFD Surge Capacity Increase 0 5 1 Hertz (Hz)
