Technical Data

FWD 08 12 20 30 45

Power supply (V/Ph/Hz) 230/1/50

Capacities

Cooling capacity on water (1) (kW) 5,2 8,3 15 18,8 30,1

Heating capacity on water (2) (kW) 6,3 11,9 18,9 20,9 38,2

Fan motor (type) 2 x direct drive centrifugal

Fan power input (3) (kW) 0,23 0,46 0,65 1,04 1,51

Current amps (3) (A) 1,1 2,2 3,1 4,7 5,5

Start-up amps (A) 3,2 5,5 9,3 14,1 16,5

Air flow

minimum (m

/h) 490 980 1400 1800 2700

nominal (m

/h) 820 1650 2300 3000 4500

maximum (m

/h) 980 1970 2600 3600 5400

Main coil

Water entering/leaving connections (type) ISO R7 rotating female

(Dia) 3/4" 3/4" 1 1/2" 1 1/2" 1 1/2"

Electric heater (accessory for blower only)

Electric power supply (V/Ph/Hz) 230/1/50 230/1/50 or 400/3/50 400/3/50 400/3/50 400/3/50

Heating capacity (kW) 2/4 8 10 12 12

Hot water coil (accessory for blower only)

Heating capacity (4) (kW) 6,3 12 17,4 22,4 34,5

G2 filter (filter box accessory)

Quantity 2 2 2 2 2

Dimensions ( LxWxth) (mm) 386x221x8 486x271x8 586x321x8 586*421*8 586*621*8

G4 filter (filter box accessory)

Quantity - 2 2 2 2

Dimensions ( LxWxth) (mm) - 486x264x48 586x314x48 586*414*48 586*614*48

Condensate pump (accessory) (type) Centrifugal

Water flow - lift height (l/h - mm) 24 - 500

Not available for FWD30 and FWD45

Sound level (L/M/H speed)

Sound pressure level (5) (dB(A)) 36/40/43 38/41/44 46/50/53 47/52/57 47/52/58

Sound power level (5) (dB(A)) 46/50/53 48/51/54 56/60/63 57/62/67 57/62/68

Unit dimensions

Width x Depth (mm) 890 x 600 1090 x 710 1290 x 820 1290 x 970 1290 x 1090

Height (mm) 250 300 350 450 650

Shipped unit dimensions

Width x Depth (mm) 933 x 644 1133 x 754 1333 x 864 1333 x 1008 1333*1133

Height (mm) 260 310 360 460 660

Weight (kg) 32 46 61 76 118

Colour galvanised steel

Recommended fuse size

Unit alone (aM/gI) (A) 8/16 8/16 8/16 8/25 8/25

Unit with electric heater (gI) (A) 16 (2kW),25 (4kW) 40 (230V),3*16 (400V) 3*20 3*25 3*25

(1) Conditions: Water entering/leaving temperature: 7/12 °C, Air inlet temperature 27/19°C DB/WB - Nominal air flow

(2) Conditions: Water entering/leaving temperature: 50/45 °C, Air inlet temperature 20°C DB - Nominal air flow

(3) At high speed with nominal air flow.

(4) Water entering/leaving temperature 90/70 °C, air inlet temperature 20 °C DB, Nominal air flow.

(5) A rectangular glass wool duct 1m50 long is placed on the blower.The measurement is taken in the room containing the blower unit.

Heat exchanger operating limits:

FWD:

*water temperature: max 100° C

*absolute service pressure: min 1 bar/max 11 bars

Accessories - Hot water coil:

*water temperature: min. +2° C/max. 100° C

*absolute service pressure: min 1 bar/max 11 bars

CGAX

015

SE-SN

CGAX

017

SE-SN

CGAX

020

SE-SN

CGAX

023

SE-SN

CGAX

026

SE-SN

CGAX

030

SE-SN

CGAX

035

SE-SN

Condenser Fan

Quantity # 1 1 2 2 2 2 2

Diameter (mm) 800

Fan / motor Type Propeller axial fan

Digit 12=1 and Digit 15=A

Fan / motor Type Fixed speed AC motor

Airowperfan m

/h 13788 13828 12362 12362 12370 12375 14687

Max Power Input Kw 0.89 0.89 0.89 + 0.89 0.89 + 0.89 0.89 + 0.89 0.89 + 0.89

0.89 /

0.89 + 0

Max Amps A 2.22 2.22 2.22 + 2.22 2.22 + 2.22 2.22 + 2.22 2.22 + 2.22

2.22 /

2.22 + 0

Motor RPM (rpm) 686 686 686 686 686 686 686

Digit 12=1 and Digit 15=C

Fan / motor Type Fixed speed AC motor / Variable speed

Airowperfan m

/h 13788 13828 12362 12362 12370 12375 14687

Max Power Input Kw 1.95 1.95 1.95 + 0.89 1.95 + 0.89 1.95 + 0.89 1.95 + 0.89

1.95 /

1.95 + 0

Max Amps A 3 3 3 + 2.22 3 + 2.22 3 + 2.22 3 + 2.22 3 / 3 + 0

Motor RPM (rpm) 686 686 686 686 686 686 686

AirowperFan (m

/h) 13788 13828 12362 12362 12370 12375 14687

Power per Motor (kW) 686 686 686 686 686 686 686

Partial Heat recovery (PHR) option

Heat-Exchanger Type Stainless steel Copper Brazed plate Heat exchanger

Heat-Exchanger Model

B3-014-14-

4.5M

B3-014-14-

4.5M

B3-014-14-

4.5M

B3-014-14-

4.5M

B3-027-14-

4.5L

B3-027-14-

4.5L

2x B3-014-

14-4.5M

Water connection size (Thread connection)

(in) -

(mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

G 1"1/4

(31.75 mm)

Water content volume (l) 0.14 0.14 0.14 0.14 0.35 0.35 2x 0.14

Dimensions (7)

Unit Length (mm) 2346 2346 2346 2346 2346 2346 2327

Unit Width (mm) 1285 1285 1285 1285 1285 1285 2250

Std Unit Height (mm) 1524 1524 1524 1524 1524 1524 1524

LN or External SP unit -

(Additionalheightconguration)

(mm) +223 +224 +225 +226 +227 +228 +232

WaterBuertankoption-

(Additionalheightconguration)

(mm) +330 +330 +330 +330 +330 +330 +330

Weights

Shipping Weight (3) (kg) 519 531 574 579 608 621 917

Operating Weight (3) (kg) 497 509 552 557 587 599 887

Option Additional shipping weight

Single pump - Standard head pressure (kg) 46 46 46 49 49 49 45

Single pump - High head pressure (kg) 51 51 51 51 51 51 49

Twin pump - Standard head pressure (kg) 70 70 70 75 75 75 75

Twin pump - High head pressure (kg) 82 82 82 82 82 82 84

Pump VFD option (kg) 0

Partial heat recovery option (kg) 1.48 1.48 1.48 1.48 3.82 3.82 2x 1.48

WaterBuertankoption (kg) 319 319 319 319 319 319 425

System data

Nb of refrigerant circuit # 1 1 1 1 1 1 2

Minimum cooling load % (6) % 50 43 50 43 50 50 22

Standard/Partial Heat Recovery Unit unit

R410A refrigerant charge Circuit1 / Circuit 2 (kg) 7.5 9.0 9.0 9.0 10.5 10.5 8

R454B refrigerant charge Circuit1 / Circuit 2 (kg) 6.0 7.0 7.0 7.0 8.5 8.5 6.5

Oil charge Circuit1 / Circuit 2 R410A & R454B (l) 6.0 6.3 6.6 6.6 6.6 7.2 6.3

POE Oil type (6) OIL058E / OIL057E

(1) Indicative performance at Evaporator water temperature : 12°C / 7°C - Condenser air temperature 35°C - for detailed performances, on a given unit,

consult Order Write Up.

(2) under 400V/3/50Hz.

(3) Rated Condition without Pump Package.

(4) Electrical & system data are indicative and subject to change without notice. Please refer to unit nameplate data.

(5) If the power line of the unit is protected by fuses gG of the same size as the disconnect switch.

(6) OIL058E or 0IL057E are European reference for POE oil and can be mixed in any proportion with OIL00078 or OIL 00080 (same oil with US reference on

compressor nameplate).

(7)Fordimensionsdetails,dimensionsofhydraulicconnections,electricalconnections,pointloadandspecicfeaturesforheatrecoveryseesubmittals

and diagrams which are supplied with every order.

General Data

Table 1 - CGAX 015-035 General Data (continued)
