Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
General Data
Table 2 - CGAX 036-060 General Data
CGAX
036
SE-SN
CGAX
039
SE-SN
CGAX
040
SE-SN
CGAX
045
SE-SN
CGAX
046
SE-SN
CGAX
052
SE-SN
CGAX
060
SE-SN
Net Cooling Capacity R410A (1) (kW) 100.6 113.6 117.9 129.3 132.5 148.9 164.9
Total Power input in cooling R410A (1) (kW) 33.2 38.1 39.6 41.7 46.8 51.3 58.0
Net cooling capacity R454B (1) (kW) 96.7 109.4 116.1 122.8 131.4 150.5 164.7
Total Power input in cooling R454B (1) (kW) 33 37.5 36.2 40.3 42.2 48.4 55.5
Unit electrical data (2) (3) (4)
Short Circuit Unit Capacity (9) (kA) 15 15 15 15 15 15 15
Power Cable Cross Section (max) mm² 150 150 150 150 150 150 150
Disconnect switch size (A) 250 250 250 250 250 250 250
Digit 12=1 and Digit 15=A
Maximum Power input (kW) 43.0 49.0 51.6 55.5 59.0 66.5 74.0
Unit rated amps (A) 73.8 81.0 90.4 95.8 100.6 110.8 127.6
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A) 197.9 213.7 212.2 221.3 233.3 243.5 253.1
Unit start up amps (with soft starter - Digit 26=B) (4) 139.1 150.5 155.4 159.3 170.1 180.3 191.1
Power factor 0.854 0.886 0.836 0.847 0.861 0.880 0.847
Digit 12=1 and Digit 15=C
Maximum Power input (kW) 44.1 50.0 53.7 56.6 61.2 68.6 76.1
Unit rated amps (A) 74.6 81.8 91.9 96.6 102.1 112.3 129.1
Unit start up amps (w/o soft starter - Digit 26=A) (4) (A) 198.7 214.5 213.7 222.1 234.8 245.0 254.6
Unit start up amps (with soft starter - Digit 26=B) (4) 139.9 151.3 156.9 160.1 171.6 181.8 192.6
Power factor 0.864 0.894 0.854 0.855 0.875 0.892 0.859
Compressor
Compressor Number per Circuit # 3 3 2 3 2 2 2
Type Scroll Scroll Scroll Scroll Scroll Scroll Scroll
Model Circuit1 / Circuit 2 12+12+12 13+13+13
10+10 /
10+10
15+15+15
10+13
/10+13
13+13 /
13+13
15+15 /
15+15
Max Compr Power input Circuit 1/Circuit 2 kW
13,7 +
13,7 + 13,7
15,7 +
15,7 + 15,7
12 + 12 /
12 + 12
17,6 +
17,6 + 17,6
12 + 15,7 /
12 + 15,7
15,7 + 15,7 /
15,7 + 15,7
17,6 + 17,6 /
17,6 + 17,6
Rated Amps Circuit1 / Circuit 2 (4) (A)
22,9 +
22,9 + 22,9
25,3 +
25,3 + 25,3
20,2 + 20,2 /
20,2 + 20,2
29,5 +
29,5 + 29,5
20,2 + 25,3 /
20,2 + 25,3
25,3 + 25,3 /
25,3 + 25,3
29,5 + 29,5 /
29,5 + 29,5
Locked Rotor Amps Circuit1 / Circuit 2 (4) (A)
147 +
147 + 147
158 +
158 + 158
142 + 142 /
142 + 142
155 +
155 + 155
142 + 158 /
142 + 158
158 + 158 /
158 + 158
155 + 155 /
155 + 155
Motor RPM (rpm) 2900 2900 2900 2900 2900 2900 2900
Oil sump heater Circuit1 / Circuit 2 (W) 0,25 / 0 0,25 / 0 0,17 / 0,17 0,25 / 0 0,17 / 0,17 0,17 / 0,17 0,17 / 0,17
Evaporator
Quantity # 1 1 1 1 1 1 1
Type Stainless steel Copper Brazed plate Heat exchanger
Evaporator model P120Tx104 P120Tx104 DP300x82 P120Tx104 DP300x82 DP300x114 DP300x114
Evaporator Water Content volume (l) 12.5 12.5 8.5 12.5 8.5 11.8 11.8
Nominal water connection size
(Grooved coupling) - Without HYM
(in) -
(mm)
2" - 60,3 2" - 60,3 3" OD - 76,1 2" - 60,3 3" OD - 76,1 3" OD - 76,1 3" OD - 76,1
Nominal water connection size
(Grooved coupling) - With HYM
(in) -
(mm)
3" OD - 76,1 3" OD - 76,1 3" OD - 76,1 3" OD - 76,1 3" OD - 76,1 3" OD - 76,1 3" OD - 76,1
Hydraulic Module Components
Single pump - Standard head pressure option
Max available Head Pressure (kPa) 103 131 133 104 114 113 178
Motor Power (kW) 1.50 2.30 2.30 2.30 2.30 2.30 2.30
Rated Amps (A) 3.50 5.03 5.03 5.03 5.03 5.03 5.03
Single pump - High head pressure option
Max available Head Pressure (kPa) 190 176 179 151 162 162 138
Motor Power (kW) 3.00 3.00 3.00 3.00 3.00 3.00 3.00
Rated Amps (A) 6.23 6.23 6.23 6.23 6.23 6.23 6.23
Twin pump - Standard head pressure option
Max available Head Pressure (kPa) 103 131 133 104 114 113 178
Motor Power (kW) 1.50 2.30 2.30 2.30 2.30 2.30 2.30
Rated Amps (A) 3.50 5.03 5.03 5.03 5.03 5.03 5.03
Twin pump - High head pressure option
Max available Head Pressure (kPa) 190 176 179 151 162 162 138
Motor Power (kW) 3.00 3.00 3.00 3.00 3.00 3.00 3.00
Rated Amps (A) 6.23 6.23 6.23 6.23 6.23 6.23 6.23
Expansion Tank Volume (l) 35 35 35 35 35 35 35
Max User water loop Volume for factory mounted
expansion tank (1)
(l) 2000 2000 2000 2000 2000 2000 2000
OptionnalwaterBuertankvolume (l) 444 444 444 444 444 444 444
Antifreeze Heater without pump package (W) 180 180 120 180 120 180 180
Antifreeze Heater with pump package (W) 340 340 280 340 280 340 340
Condenser
Type Full aluminum Micro channel heat exchanger
Quantity of coil # 2 2 2 2 2 2 2
Face area per circuit (m²) 4.46 5.93 2.96 5.93 2.96 2.96 2.96
