Installation
16 CLCH-SVN05C-EN
Table 4. Typical customer parts list
Customer Parts List
Thank you for purchasing the roof curb accessory for the Trane Performance Climate Changer™ air handler for this project.
We at Trane appreciate your business, and strive constantly to improve products. To that end, we welcome any comments
or suggestions you may have regarding this product.
Job Number
123456-1-1
E-Bolts:
20
Length (I.D.)
157.25 in.
Bolts:
60
Width (I.D.)
45.50 in.
Nuts:
80
Weight (EST.): Washers:
140
Weight:
267.33
Project Name: Self Drillers: 56
Tags:
RTU-1
Part Description Dimensions Qty
TP1301 Cross Brace
TP1301-01 Cross Brace 45.50 x 14.00 x 14.00 1
TP1301-02 Cross Brace 45.50 x 14.00 x 14.00 1
TP1302 Outer Side Plate
TP1302-01 Outer Side Plate 9.88 x 5.00 1
TP1302-02 Outer Side Plate 9.88 x 5.00 1
TP1302-03 Outer Side Plate 9.88 x 5.00 1
TP1302-04 Outer Side Plate 9.88 x 5.00 1
TP1303 Inner Corner Angle
TP1303-01 Inner Corner Angle 13.88 1
TP1303-02 Inner Corner Angle 13.88 1
TP1303-03 Inner Corner Angle 13.88 1
TP1303-04 Inner Corner Angle 13.88 1
TP1303-05 Inner Corner Angle 13.88 1
TP1303-06 Inner Corner Angle 13.88 1
TP1304 Outer Corner Angle
TP1304-01 Outer Corner Angle 9.88 1
TP1304-02 Outer Corner Angle 9.88 1
TP1304-03 Outer Corner Angle 9.88 1
TP1304-04 Outer Corner Angle 9.88 1
TP1305 Duct Support
TP1305-01 Duct Support 56.50 1
TP1305-02 Duct Support 56.50 1
TP1305-03 Duct Support 42.50 1
TP1305-04 Duct Support 42.50 1
TP1305 Duct Support Cross
TP1306-01 Duct Support Cross 45.50 1
TP1306-02 Duct Support Cross 45.50 1
TP1306-03 Duct Support Cross 45.50 1
TP1306-04 Duct Support Cross 45.50 1
TP1305 Duct Support Angle
TP1307-01 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-02 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-03 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-04 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-05 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-06 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-07 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1307-08 Duct Support Angle 5.00 x 2.00 x 2.00 1
TP1384 Side Wall
TP1384-01 Side Wall 58.88 x 14.00 x 14.00 1
TP1384-02 Side Wall 58.88 x 14.00 x 14.00 1
TP1384-03 Side Wall 58.13 x 14.00 x 14.00 1
TP1384-04 Side Wall 58.13 x 14.00 x 14.00 1
TP1384-05 Side Wall 40.25 x 14.00 x 14.00 1
TP1384-06 Side Wall 40.25 x 14.00 x 14.00 1
