Trane CSAA Installation Instructions

CLCH-SVN05C-EN 7
Dimensions and Weights
Table 1. CSAA Curb weights
Curb
height
Unit Size 3 4 6 8 10 12 14 17 21 25
14-inch
Curb end and duct
support weight
117.23 155.82 155.82 175.88 209.84 225.27 242.25 242.25 266.94 266.94
Curb side weight Take total length in inches, multiply by 0.56 pounds, and add to the above curb end & duct support weight.
18-inch
Curb end and duct
support weight
148.76 197.59 197.59 222.98 265.95 285.48 306.96 306.96 338.21 338.21
Curb side weight Take total length in inches, multiply by 1.05 pounds, and add to the above curb end & duct support weight.
22-inch
Curb end and duct
support weight
171.54 227.14 227.14 256.05 304.98 327.22 351.68 351.68 387.26 387.26
Curb side weight Take total length in inches, multiply by 1.22 pounds, and add to the above curb end & duct support weight.
26-inch
Curb end and duct
support weight
215.31 286.02 286.02 322.78 385.00 413.28 444.39 444.39 489.64 489.64
Curb side weight Take total length in inches, multiply by 2.00 pounds, and add to the above curb end & duct support weight.
30-inch
Curb end and duct
support weight
240.72 319.23 319.23 360.06 429.15 460.56 495.11 495.11 545.36 545.36
Curb side weight Take total length in inches, multiply by 2.25 pounds, and add to the above curb end & duct support weight.
36-inch
Curb end and duct
support weight
278.82 369.05 369.05 415.98 495.38 531.48 571.18 571.18 628.93 628.93
Curb side weight Take total length in inches, multiply by 2.63 pounds, and add to the above curb end & duct support weight.
Curb
height Unit Size 30 35 40 50 57 66 80 100 120
14-inch
Curb end and duct
support weight
308.62 328.68 367.27 407.39 407.39 453.70 453.70 496.91 581.80
Curb side weight Take total length in inches, multiply by 0.56 pounds, and add to the above curb end & duct support weight.
18-inch
Curb end and duct
support weight
390.95 416.34 465.17 515.95 515.95 574.54 574.54 629.23 736.65
Curb side weight Take total length in inches, multiply by 1.05 pounds, and add to the above curb end & duct support weight.
22-inch
Curb end and duct
support weight
447.31 476.22 531.82 589.64 589.64 656.36 656.36 718.63 840.95
Curb side weight Take total length in inches, multiply by 1.22 pounds, and add to the above curb end & duct support weight.
26-inch
Curb end and duct
support weight
566.00 602.77 673.47 747.00 747.00 831.85 831.85 911.03 1066.58
Curb side weight Take total length in inches, multiply by 2.00 pounds, and add to the above curb end & duct support weight.
30-inch
Curb end and duct
support weight
630.15 670.98 749.50 831.15 831.15 925.37 925.37 1013.31 1186.04
Curb side weight Take total length in inches, multiply by 2.25 pounds, and add to the above curb end & duct support weight.
36-inch
Curb end and duct
support weight
726.38 773.30 863.54 957.38 957.38 1065.66 1065.66 1166.73 1365.24
Curb side weight Take total length in inches, multiply by 2.63 pounds, and add to the above curb end & duct support weight.
Note: Example: Size 21 Performance air handler with airfoil damper mixing section, small coil section, medium access section, medium coil section, small
blank section, VFD control section, and fan section (down discharge) total unit length is 156.75 inches. Total roof curb weight for the 18-inch curb
would be 502.80 lbs (156.75 x 1.05 = 164.5875 lbs + 338.21 = 502.7975 lbs.)
