Installation: Electrical
Figure 27. PFCC leads routed through overload current transformer
Line
PFCC
Overload
Current
Transformer
Motor
Load
- OR -
Line
PFCC
Overload
Current
Transformer
Motor
Load
Note: See the attached wiring diagram for more detail.
CVGF-SVX03B-EN
79
