Trane CVHE

CVHE-SB-32A 24
Table 1
CT’s for more than 600V or more than 936A systems:
Motor RLA CT Part Number
CT Terminal
Connections
Number of primary
turns
8.0-11.9 X-13580272-01 3
12.0-17.9 X-13580272-01 2
18.0-23.9 X-13580272-02 2
24.0-35.9 X-13580272-01 1
36.0-47.9 X-13580272-02 1
48.0-72.0 X-13580272-01 1
24-36 A X-13580048-01 X1 to X2 3
28-43 A X-13580048-01 X1 to X3 3
36-54 A X-13580048-01 X1 to X2 2
43-64 A X-13580048-01 X1 to X3 2
48-72 A X-13580048-01 X1 to X4 2
60-90 A X-13580048-02 X1 to X2 2
72-108 A X-13580048-01 X1 to X2 1
86-129 A X-13580048-01 X1 to X3 1
96-144 A X-13580048-01 X1 to X4 1
120-180 A X-13580048-02 X1 to X2 1
144-216 A X-13580048-02 X1 to X3 1
168-252 A X-13580048-02 X1 to X4 1
192-288 A X-13580048-03 X1 to X2 1
240-360 A X-13580048-03 X1 to X3 1
288-432 A X-13580048-03 X1 to X4 1
336-504 A X-13580048-04 X1 to X2 1
384-576 A X-13580048-04 X1 to X3 1
480-720 A X-13580048-04 X1 to X4 1
480-720 A X-13580047-02 X1 to X2 1
576-864 A X-13580048-05 X1 to X2 1
576-864 A X-13580047-02 X1 to X3 1
720-1080 A X-13580048-05 X1 to X3 1
720-1080 A X-13580047-02 X1 to X4 1
864-1296 A X-13580047-01 X1 to X2 1
1008-1512 A X-13580047-01 X1 to X3 1
1200-1800 A X-13580047-01 X1 to X4 1
