Trane CVHE

CVHE-SB-32A 49
Table 4
Switch Bank 2
Busy Line Selection
SSD-Pin 11
SSD+ Pin 11
DTR- Pin20
RTS- Pin 4
Switches 7,8
off, on
off,off
on, on
on, off
Transmission Speed
19200
9600
4800
2400
1200
600
300
110
Switch 1,2,3
on, on, on
off, on, on
on, off, on
off, off, on
on, on, off
off, on, off
on, off, off
off, off, off
DSR Input Signal
Active
Inactive
Switch 4
on
off
Buffer
32 bytes
256 bytes
Switch 5
on
off
Busy Signal Timing
200 ms
1 second
Switch 6
on
off
DTR Signal
After power on
Printer selected
Switch 7
on
off
Not Used Switch 8
