Trane CVHE Troubleshooting

CVHE-SB-32A 60
Table 12
0 0.0132 0.0150 0.0168
1 0.0142 0.0160 0.0178
2 0.0151 0.01 70 0.0189
3 0.0161 0.0180 0.0199
4 0.0171 0.0190 0.0209
5 0.0180 0.0200 0.0220
6 0.0190 0.0210 0.0230
7 0.0199 0.0220 0.0241
8 0.0209 0.0230 0.0251
9 0.0218 0.0240 0.0262
10 0.0228 0.0250 0.0272
11 0.0237 0.0260 0.0283
12 0.0247 0.0270 0.0293
13 0.0256 0.0280 0.0304
14 0.0266 0.0290 0.0314
15 0.0275 0.0300 0.0325
16 0.0285 0.0310 0.0335
17 0.0294 0.0320 0.0346
18 0.0303 0.0330 0.0357
19 0.0313 0.340 0.0367
20 0.0322 0.0350 0.0378
25 0.0369 0.0400 0.0431
30 0.0417 0.0450 0.0483
35 0.0464 0.0500 0.0536
Voltages and Resistances of Oil Pressure Input Terminals
Min Nom Max
+5V to GND 4.75 5.0 5.25
V- to GND 1.6 2.0 2.5
V+ to GND 1.6 2.0 2.5
Table 11
Pressure vs Voltage for Oil Pressures (Continued)
Oil Pressure
(PSIG)
Differential Voltage
Min Nom Max
