CVHE-SB-32A 65
Table 15
Evap. Entering and Leaving Water Temp.
A1 Analog Input
Thermistor Accuracy = 0.54°°F from 15 to 140°°F
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table for a
pullup resistor of 24900 Ohms.
Used to sense temperatures at the following point:
1. Evap. Entering and Leaving Water Temp. Pair CVHE/F/G
Table 15
Temp °°F Min Res Max Res Min Vterm Max Vterm
15.0 53738 55532 3.399 3.441
20.0 46161 47678 3.231 3.274
21.0 44791 46259 3.196 3.240
22.0 43466 44886 3.162 3.206
23.0 42183 43558 3.127 3.171
24.0 40943 42273 3.092 3.137
25.0 39742 41029 3.058 3.102
26.0 38580 39826 3.022 3.067
27.0 37455 38661 2.987 3.032
28.0 36367 37534 2.952 2.997
29.0 35312 36442 2.916 2.962
30.0 34292 35386 2.881 2.926
31.0 33304 34363 2.845 2.891
32.0 32358 33365 2.810 2.855
33.0 31448 32423 2.775 2.820
34.0 30566 31511 2.740 2.785
35.0 29713 30628 2.705 2.750
36.0 28886 29773 2.671 2.715
37.0 28086 28944 2.636 2.681
38.0 27310 28142 2.601 2.646
39.0 26559 27364 2.566 2.611
40.0 25830 26611 2.532 2.577
41.0 25125 25881 2.497 2.542
42.0 124441 25174 2.463 2.508
43.0 23778 24489 2.429 2.473
44.0 23135 23824 2.395 2.439
45.0 22512 23180 2.361 2.405
To Next Page
