CVHE-SB-32A 67
Table 16
Saturated Cond. Refrigerant Temp.
A2 Analog Input
Thermistor Accuracy = 0.54°°F from 15 to 140°°F
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table for a
pullup resistor of 6980 Ohms.
Saturated Cond. Refrigerant Temp CVHE/F/G
Table 16
Temp °°F Min Res Max Res Min Vterm Max Vterm
15.0 53738 55532 4.416 4.435
17.0 50554 52231 4.384 4.404
19.0 47577 49145 4.350 4.372
21.0 44791 46259 4.316 4.338
23.0 42183 43558 4.280 4.303
25.0 39742 41029 4.242 4.266
27.0 37455 38661 4.204 4.228
29.0 35312 36442 4.163 4.189
31.0 33304 34363 4.122 4.149
33.0 31448 32423 4.080 4.107
35.0 29713 30628 4.037 4.065
37.0 28086 28944 3.992 4.021
39.0 26559 27364 3.946 3.976
41.0 25125 25881 3.900 3.930
43.0 23778 24489 3.852 3.883
45.0 22512 23180 3.803 3.835
47.0 21322 21950 3.752 3.785
49.0 20203 20794 3.701 3.735
51.0 19150 19706 3.649 3.684
53.0 18158 18682 3.596 3.631
55.0 17225 17718 3.542 3.578
57.0 16346 16810 3.488 3.524
59.0 15517 15955 3.432 3.469
61.0 14735 15148 3.376 3.413
63.0 13998 14388 3.319 3.357
65.0 13303 13670 3.262 3.300
67.0 12646 12993 3.204 3.243
