CVHE-SB-32A 78
Table 21
Saturated Evap. Refrigerant Temp.
A4 Analog Input
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table
for a pullup resistor of 38300 Ohms.
Used to sense temperatures at the following point:
1. Saturated Evap. Refrigerant Temp. CVHE/F/G
Table 21
Temp °°F Min Res Max Res Min Vterm Max Vterm
10.0 62706 64832 3.084 3.129
11.0 60788 62843 3.047 3.093
12.0 58935 60921 3.011 3.057
13.0 57144 59063 2.974 3.020
14.0 55412 57268 2.937 2.984
15.0 53738 55532 2.900 2.947
16.0 52119 53854 2.863 2.910
17.0 50554 52231 2.826 2.873
18.0 49040 50663 2.789 2.836
19.0 47577 49145 2.752 2.799
20.0 46161 47678 2.715 2.762
21.0 44791 46259 2.678 2.725
22.0 43466 44886 2.641 2.688
23.0 42183 43558 2.604 2.651
24.0 40943 42273 2.567 2.614
25.0 39742 41029 2.530 2.577
26.0 38580 39826 2.493 2.540
27.0 37455 38661 2.457 2.503
28.0 36367 37534 2.420 2.467
29.0 35312 36442 2.384 2.430
30.0 34292 35386 2.347 2.394
31.0 33304 34363 2.311 2.357
32.0 32358 33365 2.276 2.321
33.0 31448 32423 2.240 2.286
34.0 30566 31511 2.206 2.250
35.0 29713 30628 2.171 2.216
36.0 28886 29773 2.137 2.181
37.0 28086 28944 2.102 2.146
