AFDK-SVU01C-EN 59
Wiring Schematics
Table 31. Wiring diagrams
Type Number
Unit Mounted Adaptive Frequency™ Drive 405–608 A 
LiquiFlo 2, Frame 3
2311-0453
Unit Mounted Adaptive Frequency Drive 900–1210 A 
LiquiFlo 2, Frame 4
2311-0454
Field Connection Diagram - Simplex - Trane Supplied
Adaptive
Frequency Drive
2311-0565
Remote Mounted Adaptive Frequency Drive 405–608 A 
LiquiFlo 2, Frame 3
2309-7647
Remote Mounted Adaptive Frequency Drive 900–1210 A 
LiquiFlo 2, Frame 4
2309-7646
Note: Wiring diagr
ams are available via e-Library.
