Wiring Diagrams
34 SO-SVN037A-EN
Notes:
•a - All notes and hazard notifications listed in “Wiring
Diagrams,” p. 33 of this manual apply to this drawing
•b - IPC BUS
•c - Dual relay LLID to remove (its functions will be replaced
by the Quad Relay)
•d - Oil tank junction box
•e - Customer provided
•f - Oil tank heater
•g - Evaporator water pump (optional)
•h - Condenser water pump (required)
•i - Ice building indicator (optional)
Figure 67. Existing LLIDs to remove before installing quad relay LLID
