Trane CXAJ series User Manual

10
Unit Installation
AIR OUT
AIR IN
AIR IN
AIR IN
SERVICE
SPACE
≥1
.2M
≥1.2M
≥1.2M
≥1
.2M
610
mm
য় ߢ
ටᇵฅྨ.
ሞྼႪമසࡕփൎ܏ۉᇸ,ࣷሰׯჹዘڦ
ሞྼႪമൎ܏໯ᆶڦۉᇸ,Ԉઔᄫևݴ.
ᆶۉླ၃!
injury or death.
servicing can cause severe personal
Failure to disconnect power before
BEFORE SERVICING.
INCLUDING REMOTE DISCONNECTS
DISCONNECT ALL ELECTRIC POWER
HAZARDOUS VOLTAGE !
WARNING
য় ߢ
ටᇵฅྨ.
ሞྼႪമසࡕփൎ܏ۉᇸ,ࣷሰׯჹዘڦ
ሞྼႪമൎ܏໯ᆶڦۉᇸ,Ԉઔᄫևݴ.
ᆶۉླ၃!
injury or death.
servicing can cause severe personal
Failure to disconnect power before
BEFORE SERVICING.
INCLUDING REMOTE DISCONNECTS
DISCONNECT ALL ELECTRIC POWER
HAZARDOUS VOLTAGE !
WARNING
Installation Space Diagram
PUMP
     
WA
TER OUTLET
WA
TER INLET
MODULAR
GROUP C
MODULAR
GROUP B
MODULAR
GROUP A
≥1.5M ≥1.5M
Multi-module Combination Diagram (Reverse Return Connection)
Note: each CXAJ/CGAJ045/065 multi-module combination includes 8 units at most, and each CXAJ/CGAJ130 multi-
module combination includes 4 units at most. Direct return connection is not allowed.
