18 WSHP-SVN08B-EN
Electrical
Requirements
Table F2: Blower External Static Pressure with Return Air Door (RAD), with filter
1 The NO "Ducted" option is for non-ducted (free return) units.
2 Units specified as "non-ducted" (free return) are factory wired to low-speed.
3 Units specified as "ducted" are factory wired to high-speed.
Table E1: Electrical Performance
Model No.
Speed
Tap
Ducted
Min
CFM
Max
CFM
External Static Pressure (in. of wg)
0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5 0.55 0.6 0.65 0.7
GET009HighYes280482-451417378342303---------
GET009LowYes- - -336324304278----------
GET009HighNo- -345--------------
GET009LowNo- -280--------------
GET012 High Yes 380 481 - - - 459 436 413 389 363 - - - - - - -
GET012 Low Yes - - - 420 400 382 362 - - - - - - - - - -
GET012 High No - - 470 - - - - - - - - - - - - - -
GET012 Low No - - 380 - - - - - - - - - - - - -
GET015HighYes475652-----642621601574551525493457419679
GET015LowYes- - -572556541525509495476-------
GET015HighNo- -575--------------
GET015LowNo- -475--------------
GET018 High Yes 570 800 - - - - - - - 774 747 722 698 668 639 607 578
GET018 Low Yes - - - 623 617 603 588 571 555 - - - - - - - -
GET018 High No - - 690 - - - - - - - - - - - - - -
GET018 Low No - - 524 - - - - - - - - - - - - - -
GET024HighYes760974----927907880858830799777743---
GET024LowYes- - -831806789767746726--------
GET024HighNo- -940--------------
GET024LowNo- -760--------------
GET036 High Yes 1135 1344 - - - - - - - - - - 1250 1219 1188 1161 1125
GET036 Low Yes - - - 1177 1169 1159 1144 1136 1119 1102 1084 1061 - - - - -
GET036 High No - - 1280 - - - - - - - - - - - - - -
GET036 Low No - - 1140 - - - - - - - - - - - - - -
Model No. Oversized Blower Volts
Tot a l
FLA
Comp.
RLA
Comp.
LRA
Blower
Motor
FLA
Blower
Motor
HP
Minimum
Circuit
Ampacity
Overcurrent
Protective
Device
GET009 No 208/60/1 4.0 3.4 22.2 0.6 1/10 4.9 15
GET009 No 220-240/50/1 3.6 3.1 18.8 0.5 1/10 4.4 15
GET009 No 230/60/1 4.0 3.4 22.2 0.6 1/10 4.9 15
GET009 No 265/60/1 3.6 3.1 18.8 0.5 1/10 4.4 15
GET012 No 208/60/1 5.7 5.0 27.9 0.7 1/8 6.9 15
GET012 No 220-240/50/1 4.9 4.3 22.2 0.6 1/8 6.0 15
GET012 No 230/60/1 5.7 5.0 27.9 0.7 1/8 6.9 15
GET012 No 265/60/1 4.9 4.3 22.2 0.6 1/8 6.0 15
GET015 No 208/60/1 6.1 5.4 29.0 0.7 1/8 7.5 15
GET015 No 220-240/50/1 5.4 4.8 27.0 0.6 1/8 6.6 15
GET015 No 230/60/1 6.1 5.4 29.0 0.7 1/8 7.5 15
GET015 No 265/60/1 5.4 4.8 27.0 0.6 1/8 6.6 15
GET018 No 208/60/1 9.3 7.6 45.0 1.7 1/5 11.2 15
GET018 No 220-240/50/1 7.4 6.3 32.0 1.1 1/5 9.0 15
GET018 No 230/60/1 9.3 7.6 45.0 1.7 1/5 11.2 15
GET018 No 265/60/1 7.4 6.3 32.0 1.1 1/5 9.0 15
GET024 No 208/60/1 13.1 10.9 56.0 2.2 1/5 15.8 25
GET024 No 220-240/50/1 11.7 9.9 55.0 1.8 1/5 14.2 20
GET024 No 230/60/1 13.1 10.9 56.0 2.2 1/5 15.8 25
GET024 No 265/60/1 11.7 9.9 55.0 1.8 1/5 14.2 20
GET036 No 208/60/1 19.3 16.0 82.0 3.3 1/2 23.3 35
GET036 No 220-240/50/1 16.4 13.6 64.0 2.8 1/2 19.8 30
GET036 No 230/60/1 19.3 16.0 82.0 3.3 1/2 23.3 35
GET036 No 265/60/1 16.4 13.6 64.0 2.8 1/2 19.8 30
