Trane Horizon OADG Series User Manual

Appendix
OAU-SVX007A-EN 107
Table 27. OAD units
Evaporator
Thickness MERV Qty Height Width
2 in.(5.1 cm)
8
6 24 in (63.5 cm) 18 in.(45.7 cm)
13
4 in.(10.2 cm) 14 6 24 in (63.5 cm) 18 in.(45.7 cm)
ERV Module
Return Air
Thickness MERV Qty Height Width
2 in.(5.1 cm) 8 6 20 in.(50.8 cm) 20 in.(50.8 cm)
Outside Air
(a)
(a) No filters will be provided on the outside air path of the auxiliary module if electric
preheat is provided.
Thickness MERV Qty Height Width
2 in.(5.1 cm) 8 6 20 in.(50.8 cm) 20 in.(50.8 cm)
Inlet Hood
Thickness Material Qty Height Width
2 in.(5.1 cm) Aluminum Mesh 6 20 in.(50.8 cm) 20 in.(50.8 cm)
Table 28. OANG units
Evaporator (40 to 50 ton - 4 and 6 row coils; 55 to 100 ton - 6 row coils)
Thickness MERV Qty Height Width
2 in.(5.1 cm)
8
15 20 in.(50.8 cm) 18 in.(45.7 cm)
13
4 in.(10.2 cm) 14 15 20 in.(50.8 cm) 18 in.(45.7 cm)
Evaporator (55 to 100 ton - 4 row coils)
Thickness MERV Qty Height Width
2 in.(5.1 cm)
8
12 20 in.(50.8 cm) 25 in.(63.5 cm)
13
4 in.(10.2 cm) 14 12 20 in.(50.8 cm) 25 in.(63.5 cm)
ERV Module
Return Air
Thickness MERV Qty Height Width
2 in.(5.1 cm) 8 15 24 in.(61 cm) 18 in.(45.7 cm)
Outside Air
(a)
(a) No filters will be provided on the outside air path of the auxiliary module if electric
preheat is provided.
Thickness MERV Qty Height Width
2 in.(5.1 cm) 8 15 24 in.(61 cm) 18 in.(45.7 cm)
Inlet Hood
Thickness Material Qty Height Width
2 in.(5.1 cm) Aluminum Mesh 12 24 in.(61 cm) 24 in.(61 cm)
