Trane Horizon OADG Series User Manual

Unit Clearances, Curb Dimensions, and Dimensional Data
54 OAU-SVX007A-EN
Dimensional Data
Notes:
• Sound attenuation package will add 16 in. (40.6 cm) to the
height of the condenser fan section.
• Units with no cooling will have the same dimensions, less
the condensing section.
• Units with chilled water cooling will have the same
dimensions, less the condensing section, and with an 18
in. (45.7 cm) deep pipe cabinet added.
• Refer to project-specific unit submittals.
Figure 89. Unit dimensional data for OAD unit with no powered exhaust or ERV, in. (cm)
OPTIONAL
BAROMETRIC
RELIEF
DAMPER
LOCATION
25.680
(65.2)
HR
25.680
(65.2)
HR
63.000
(160)
8.660
(22)
4.660
(11.8)
31.994
(81.3)
95.281
(242)
4.000
(10.2)
HS DUCT
FLANGE
27.060
(68.7)
23.500
(59.7)
HS
23.500
(59.7)
HS
6.250
(15.9)
2.689
(6.8)
38.845
(98.7)
4.000
(10.2)
HR
DUCT FLANGE
36.451
(92.6)
110.437
(280.5)
146.888
(373.1)
8.063
(20.5)
7.094
(18)
68.594
(174.2)
29.000
(73.7)
110.000
(279.4)
GAS
HEAT
ONLY
5.250
(13.3)
5.250
(13.3)
13.000
(33)
VR
46.000
(116.8)
VR
8.500
(21.6)
52.500
(133.4)
VS
28.000
(71.1)
26.500
(67.3)
VS
33.500
(85.1)
9.000
(22.9)
