Unit Clearances, Curb Dimensions, and Dimensional Data
OAU-SVX007A-EN 55
Notes:
• Sound attenuation package will add 16 in. (40.6 cm) to the
height of the condenser fan section.
• Units with no cooling will have the same dimensions, less
the condensing section.
• Units with chilled water cooling will have the same
dimensions, less the condensing section, and with an 18
in. (45.7 cm) deep pipe cabinet added.
• Refer to project-specific unit submittals.
Figure 90. Unit dimensional data for OAD cabinet with powered exhaust but no ERV, in. (cm)
16.101
(40.9)
P.E. DAMPER HOOD
P.E. ACCESS DOOR
31.994
(81.3)
63.437
(161.1)
63.000
(160)
4.000
(10.2)
26.500
(67.3)
VS
13.000
(33)
VR
33.500
(85.1)
46.000
(116.8)
VR
52.500
(133.4)
VS
28.000
(71.1)
8.500
(21.6)
5.250
(13.3)
5.250
(13.3)
44.910
(114.1)
GAS
HEAT
ONLY
7.094
(18)
146.888
(373.1)
2.689
(6.8)
27.060
(68.7)
110.437
(280.5)
36.451
(92.6)
146.000
(370.8)
8.063
(20.5)
38.845
(98.7)
68.594
(174.2)
6.250
(15.9)
23.500
(59.7)
HS
23.500
(59.7)
HS
29.000
(73.7)
61.750
(156.8)
27.500
(69.9)
HR
19.500
(49.5)
HR
