Trane Horizon OADG Series User Manual

Unit Clearances, Curb Dimensions, and Dimensional Data
OAU-SVX007A-EN 61
Notes:
• Units with no cooling will have the same dimensions, less
the condensing section.
• Units with chilled water cooling will have the same
dimensions, less the condensing section, and with an 18
in. (45.7 cm) deep pipe cabinet added.
• Refer to project-specific unit submittals.
Figure 101. Unit dimensional data for OAN cabinet with ERV, in. (cm)
51.000
(129.5)
HS
32.217
(81.8)
HS
33.346
(84.7)
36.110
(91.7)
6.500
(16.5)
85.404
(216.9)
35.000
(88.9)
HR
300.000
(762)
40.000
(101.6)
HR
4.501
(11.4)
334.332
(849.2)
300.372
(762.9)
95.250
(241.9)
63.597
(161.5)
7.013
(17.8)
33.959
(86.3)
76.500
(194.3)
VR
5.500
(14)
43.000
(109.2)
VS
20.000
(50.8)
VR
73.500
(186.7)
VS
76.154
(193.4)
11.000
(27.9)
VE
76.500
(194.3)
VE
102.000
(259.1)
10.500
(26.7)
10.750
(27.3)
10.750
(27.3)
10.750
(27.3)
10.750
(27.3)
19.000
(48.3)
98.000
(248.9)
9.194
(23.4)
10.514
(26.7)
107.518
(273.1)
2.000
(5.1)
HS/HR
DUCT FLANGE
TYPICAL
109.194
(277.4)
