Unit Weight and Rigging
OAU-SVX007A-EN 63
OAB*072 1255 1736 47.5 23.8 31% 24% 27% 18%
OAB*084 1255 1736 46.5 24.0 29% 25% 28% 19%
OAB*096 1255 1736 46.7 24.1 31% 22% 30% 17%
OAB*108 1255 1736 46.2 24.0 27% 27% 25% 21%
OAG*120 2437 4546 60.2 34.7 29% 24% 26% 21%
OAG*144 2437 4546 59.5 34.9 26% 27% 24% 24%
OAG*180 2437 4546 59.3 34.7 28% 26% 26% 21%
OAG*210 2437 4546 60.7 35.5 26% 26% 24% 24%
OAG*240 2437 4546 59.5 34.6 29% 24% 26% 20%
OAG*264 2437 4546 59.9 34.4 26% 28% 23% 24%
OAG*300 2437 4546 58.8 35.2 28% 24% 27% 20%
OAG*360 2437 4546 58.9 34.2 28% 26% 25% 21%
OADG010 2209 3578 54 41.1 20% 15% 36% 29%
OANG070 2209 3578 54.2 41.7 19% 15% 36% 30%
OADG015 2209 3578 53.3 41.1 19% 16% 36% 29%
OADG012 2430 3585 54.1 41.3 23% 11% 39% 26%
OADG017 2430 3585 53.4 41 21% 14% 37% 28%
OADG020 6220 8111 87.2 50.1 24% 26% 26% 24%
OANG040 6220 8111 87.2 50.1 24% 26% 26% 24%
OANG045 6220 8111 87.2 50.1 24% 26% 26% 24%
OANG050 6565 8505 91.4 50.2 24% 26% 26% 24%
OANG055 6565 8505 91.4 50.2 24% 26% 26% 24%
OANG060 6881 8883 96.0 50.5 24% 26% 26% 24%
OANG080 7038 9058 95.6 50.7 24% 26% 26% 24%
(a) Refer to Figure 102, p. 66 and Figure 103, p. 66 for corner locations.
Table 1. Typical unit weight, center of gravity, and corner weights (percentage of total weight) - air cooled DX units
without powered exhaust or ERV (continued)
Model Number
Weight (lb) Center-of-gravity (in.) Corner weight (% of total weight)
(a)
Min Max Length Width Corner A Corner B Corner C Corner D
Table 2. Typical unit weight, center of gravity, and corner weights (percentage of total weight) - air cooled DX units with
powered exhaust but without ERV
Model Number
Weight (lb) Center-of-gravity (in.) Corner weight (% of total weight)
(a)
Min Max Length Width Corner A Corner B Corner C Corner D
OAK*144 3421 6240 58.4 37.7 20% 17% 28% 35%
OAK*180 3421 6240 58.4 37.0 27% 11% 34% 28%
OAK*210 3421 6240 56.7 36.9 26% 13% 34% 28%
OAK*240 3421 6240 56.7 36.9 26% 13% 34% 28%
OAK*264 3421 6240 56.7 36.9 26% 13% 34% 28%
OAK*300 3421 6240 56.7 36.9 26% 13% 34% 28%
OAK*360 3421 6240 55.0 36.6 27% 12% 36% 25%
OAN*360 5629 7814 71.9 39.5 19% 22% 28% 31%
OAN*420 5629 7814 74.5 41.0 17% 22% 26% 35%
OAN*480 5629 7814 74.5 41.0 17% 22% 26% 35%
OAN*540 5629 7814 73.4 41.5 18% 20% 29% 33%
OAN*600 5629 7814 77.0 41.2 18% 21% 26% 36%
OAN*648 5629 7814 75.2 41.4 15% 23% 24% 37%
