Unit Weight and Rigging
OAU-SVX007A-EN 65
OAK*360 4508 6337 81.9 38.0 23% 13% 36% 27%
OAN*360 6690 8621 101.1 41.0 18% 21% 30% 32%
OAN*420 6690 8621 101.1 41.0 18% 21% 30% 32%
OAN*480 6690 8621 103.2 40.0 19% 22% 28% 31%
OAN*540 6690 8621 105.0 41.5 18% 20% 29% 33%
OAN*600 6690 8621 100.0 41.0 19% 20% 31% 30%
OAN*648 6690 8621 100.9 41.2 16% 22% 29% 33%
OAB*036 1740 2526 68.1 24.3 31% 22% 29% 18%
OAB*048 1740 2526 68.9 24.0 31% 23% 27% 19%
OAB*060 1740 2526 67.0 24.1 28% 25% 26% 20%
OAB*072 1740 2526 67.0 24.4 25% 28% 24% 23%
OAB*084 1740 2526 68.3 24.4 28% 26% 25% 22%
OAB*096 1740 2526 67.3 24.2 30% 24% 28% 19%
OAB*108 1740 2526 68.1 24.0 28% 26% 25% 21%
OAG*120 3879 5972 89.4 35.3 28% 24% 23% 25%
OAG*144 3879 5972 84.3 38.8 23% 24% 26% 26%
OAG*180 3879 5972 88.1 35.1 25% 27% 21% 27%
OAG*210 3879 5972 88.2 35.2 31% 22% 26% 21%
OAG*240 3879 5972 87.4 35.2 29% 23% 25% 23%
OAG*264 3879 5972 85.8 35.1 24% 28% 21% 26%
OAG*300 3879 5972 87.0 36.0 27% 24% 24% 25%
OAG*360 3879 5972 87.0 36.0 27% 24% 24% 25%
OADG010 3405 4744 78.8 38.3 20% 19% 36% 24%
OADG012 3405 4744 78.4 38.3 20% 19% 36% 25%
OADG015 3405 4744 78 38.5 22% 17% 38% 23%
OADG017 3605 4944 77.3 38.7 21% 18% 38% 23%
OADG020 3605 4944 78.8 39.3 18% 20% 36% 27%
OANG040 8536 11563 143.4 49.2 24% 25% 30% 21%
OANG045 8536 11563 143.4 49.2 24% 25% 30% 21%
OANG050 8536 11563 143.4 49.2 24% 25% 30% 21%
OANG055 8883 11957 146.2 49.3 24% 25% 30% 21%
OANG060 8883 11957 146.2 49.3 24% 25% 30% 21%
OANG070 9199 12335 149.4 49.4 24% 25% 30% 21%
OANG080 9356 12510 151.8 49.5 24% 25% 30% 21%
(a) Refer to Figure 102, p. 66 and Figure 103, p. 66 for corner locations.
Table 3. Typical unit weight, center of gravity, and corner weights (percentage of total weight) - air cooled DX units with
powered exhaust and ERV (continued)
Model Number
Weight (lb) Center-of-gravity (in.) Corner weight (% of total weight)
(a)
Min Max Length Width Corner A Corner B Corner C Corner D
