Unit Weight and Rigging
OAU-SVX007A-EN 69
Table 5. Typical unit weights—units with auxiliary
cabinet
Model
Number
Operating Weight (lb) Shipping Weight (lb)
Min Max Min Max
OABE036* 1657 1841 1905 2089
OABE048* 1674 1858 1922 2106
OABE060* 1674 1858 1922 2106
OABE072* 1722 1906 1970 2154
OABE084* 1722 1906 1970 2154
OABE096* 1754 1938 2002 2186
OABE108* 1798 1982 2046 2230
OAGE120* 4402 5111 4402 5111
OAGE144* 4361 5161 4361 5161
OAGE180* 4367 5167 4367 5167
OAGE210* 4531 5331 4531 5331
OAGE240* 4606 5424 4606 5424
OAGE264* 4643 5460 4643 5460
OAGE300* 4763 5590 4763 5590
OAGE360* 4784 5612 4784 5612
OAKE144* 4068 4733 4068 4733
OAKE180* 4068 4733 4068 4733
OAKE210* 4487 5304 4487 5304
OAKE240* 4515 5332 4515 5332
OAKE264* 4515 5332 4515 5332
OAKE300* 4499 5359 4499 5359
OAKE360* 4507 5367 4507 5367
OANE360* 6607 7590 6607 7590
OANE420* 6922 7905 6922 7905
OANE480* 7015 8027 7015 8027
OANE540* 7082 8039 7082 8039
OANE600* 7227 8309 7227 8309
OANE648* 7239 8321 7239 8321
Note: Minimum and maximum weights vary widely due to the highly configurable
nature of the product.
Table 6. Typical unit weight—units with horizontal
return section—no auxiliary cabinet
Model
Number
Operating Weight (lb) Shipping Weight (lb)
Min Max Min Max
OABE036* 1172 1356 1420 1604
OABE048* 1189 1373 1437 1621
OABE060* 1189 1373 1437 1621
OABE072* 1237 1421 1485 1669
OABE084* 1237 1421 1485 1669
OABE096* 1269 1453 1517 1701
OABE108* 1313 1497 1561 1745
OAGE120* 2456 2964 2456 2964
OAGE144* 2506 3014 2506 3014
OAGE180* 2512 3021 2512 3021
OAGE210* 2676 3184 2676 3184
OAGE240* 2752 3278 2752 3278
OAGE264* 2788 3314 2788 3314
OAGE300* 2908 3444 2908 3444
OAGE360* 2930 3466 2930 3466
OAKE144* 3200 3865 3200 3865
OAKE180* 3036 3701 3036 3701
OAKE210* 3318 4135 3318 4135
OAKE240* 3346 4163 3346 4163
OAKE264* 3346 4163 3346 4163
OAKE300* 3350 4210 3350 4210
OAKE360* 3424 4284 3424 4284
OANE360* 5241 6224 5241 6224
OANE420* 5556 6539 5556 6539
OANE480* 5649 6661 5649 6661
OANE540* 5716 6673 5716 6673
OANE600* 5880 6962 5880 6962
OANE648* 5892 6974 5892 6974
Note: Minimum and maximum weights vary widely due to the highly configurable
nature of the product.
