Trane Hyperion AAM8A0C48V41CA User Manual

TAM812
*AM8A0C60 AIRFLOW PERFORMANCE
CONSTANT CFM MODE / CONSTANT TORQUE MODE
OUTDOOR
MULTIPLIER
(TONS)
COOLING
AIRFLOW
SETTING
Airflow
Power
EXTERNAL STATIC PRESSURE (Constant CFM / Constant Torque)
HEATING
AIRFLOW
SETTING
Airflow
Power
EXTERNAL STATIC PRESSURE
0.1 0.3 0.5 0.7 0.9 0.1 0.3 0.5 0.7 0.9
3.5 tons
290
CFM/ton
CFM
Watts
1040 / 1151
94 / 119
1068 / 1056
151 / 148
1075 / 941
203 / 168
1066 / 799
247 / 175
1046 / 607
283 / 165
290
CFM/ton
CFM
Watts
1039
95
1065
151
1071
203
1063
247
1045
283
370
CFM/ton
CFM
Watts
1312 / 1343
171 / 178
1332 / 1264
236 / 210
1336 / 1174
296 / 235
1329 / 1068
349 / 250
1314 / 945
392 / 251
350
CFM/ton
CFM
Watts
1247
150
1266
213
1270
270
1263
321
1248
363
400
CFM/ton
CFM
Watts
1408 / 1496
206 / 238
1425 / 1426
274 / 273
1429 / 1346
337 / 301
1423 / 1256
393 / 319
1410 / 1154
440 / 325
400
CFM/ton
CFM
Watts
1407
206
1423
274
1426
337
1421
392
1409
439
450
CFM/ton
CFM
Watts
1565 / 1650
274 / 312
1579 / 1585
348 / 348
1584 / 1512
416 / 378
1580 / 1432
477 / 398
1569 / 1343
529 / 407
450
CFM/ton
CFM
Watts
1564
274
1578
348
1582
416
1578
476
1569
529
4 tons
290
CFM/ton
CFM
Watts
1186 / 1304
131 / 164
1208 / 1223
192 / 196
1213 / 1128
248 / 220
1206 / 1018
297 / 234
1189 / 887
337 / 233
290
CFM/ton
CFM
Watts
1185
131
1206
192
1210
248
1203
297
1187
337
370
CFM/ton
CFM
Watts
1480 / 1514
235 / 245
1495 / 1444
306 / 280
1499 / 1365
372 / 308
1495 / 1277
430 / 327
1482 / 1177
479 / 334
350
CFM/ton
CFM
Watts
1407
206
1423
274
1426
337
1421
392
1409
439
400
CFM/ton
CFM
Watts
1587 / 1689
285 / 332
1602 / 1625
360 / 369
1606 / 1554
429 / 399
1602 / 1475
490 / 420
1592 / 1399
543 / 430
400
CFM/ton
CFM
Watts
1587
285
1600
360
1604
428
1601
490
1592
543
450
CFM/ton
CFM
Watts
1770 / 1873
386 / 443
1784 / 1813
468 / 481
1789 / 1747
543 / 512
1788 / 1675
612 / 534
1782 / 1597
671 / 546
450
CFM/ton
CFM
Watts
1770
385
1783
467
1788
543
1788
611
1782
671
4.5 tons **†
290
CFM/ton
CFM
Watts
1322 / 1431
174 / 211
1340 / 1358
240 / 245
1345 / 1274
300 / 271
1338 / 1179
353 / 288
1323 / 1069
397 / 292
290
CFM/ton
CFM
Watts
1321
174
1338
240
1342
300
1336
352
1322
396
370 †
CFM/ton
CFM
Watts
1646 / 1667
315 / 320
1660 / 1602
392 / 357
1665 / 1530
463 / 386
1662 / 1451
527 / 407
1653 / 1363
582 / 417
350
CFM/ton
CFM
Watts
1564
274
1578
348
1582
416
1578
476
1569
529
400
CFM/ton
CFM
Watts
1770 / 1873
386 / 443
1784 / 1813
468 / 481
1789 / 1747
543 / 512
1788 / 1675
612 / 534
1781 / 1597
671 / 546
400 †
CFM/ton
CFM
Watts
1770
385
1783
467
1788
543
1788
611
1782
671
450
CFM/ton
CFM
Watts
1989 2099
535 / 612
2004 / 2042
627 / 650
2012 / 1980
712 / 681
2013 / 1913
788 / 703
2009 / 1842
855 / 716
450
CFM/ton
CFM
Watts
1989
534
2003
626
2011
711
2014
788
2011
856
5 tons
290
CFM/ton
CFM
Watts
1452 / 1557
224 / 265
1469 / 1489
294 / 301
1473 / 1413
358 / 329
1468 / 1327
415 / 348
1455 / 1231
463 / 356
290
CFM/ton
CFM
Watts
1452
224
1467
294
1471
358
1466
415
1454
463
370
CFM/ton
CFM
Watts
1817 / 1826
415 / 451
1831 / 1765
499 / 451
1837 / 1698
576 / 481
1837 / 1624
647 / 503
1831 / 1544
708 / 515
350
CFM/ton
CFM
Watts
1723
357
1736
437
1741
511
1740
578
1734
636
400
CFM/ton
CFM
Watts
1964 / 2073
516 / 590
1978 / 2015
607 / 629
1986 / 1953
690 / 660
1987 / 1886
766 / 682
1983 / 1814
832 / 695
400
CFM/ton
CFM
Watts
1964
515
1978
606
1985
690
1988
766
1985
833
450
CFM/ton
CFM
Watts
2231 / 2347
741 / 842
2245 / 2292
842 / 879
2252 / 2233
934 / 908
2252 / 2171
1015 / 930
2185 / 2104
1024 / 941
450
CFM/ton
CFM
Watts
2232
741
2245
842
2252
934
2252 1016
2186 1023
1. * Models start with "A" or "T" 2. † Factory Setting 3. ** Not an actual OD size 4. Status LED will blink once per 100 CFM requested. In torque mode, actual airflow may be lower. 5. Torque mode will reduce airflow when static is above approximately 0.4" water column.
6. If the air handler is applied in downflow or horizontal configurations, the airflow should not exceed 2000 CFM. Airflow above 2000 CFM could result in water blow-off. 7. All heating modes default to Constant CFM. 8. Cooling airflow values are with wet coil, no filter
MODEL NO.
BAYEVAC05BK1AA
BAYEVAC05LG1AA
BAYEVAC08BK1AA
BAYEVAC08LG1AA
BAYEVAC10BK1AA
BAYEVAC10LG1AA BAYEVAC10LG3AA BAYEVBC15BK1AA BAYEVCB15LG3AA BAYEVBC20BK1AA BAYEVCC25BK1AA
*AM8A0C60V51SA
A
1063/1188 1063/1500 1125/1500 1000/1188 1125/1563 1250/1625 1500/1750 1625/1813
WITHOUT HEAT PUMP / WITH HP
SEE AIR HANDLER NAMEPLATE
MINIMUM HEATER AIRFLOW CFM - HEATER MATRIX
AM8A0C60 Minimum Heating Airflow Settings NOTE: Minimum auxiliary heating airflow is automatically configured by the air handler model and the auxiliary heater model number. This is not field adjustable.
