Installation
Unit Clearances
Figure 8 illustrates the minimum operating and service clearances for either a single or multiple
unit installation. These clearances are the minimum distances necessary to assure adequate
serviceability, cataloged unit capacity, and peak operating efficiency.
Providing less than the recommended clearances may result in condenser coil starvation, “short-
circuiting” of exhaust and economizer airflows, or recirculation of hot condenser air.
Unit Dimensions & Weight Information
Description Reference
Air-Cooled Condenser
Unit dimensions, 20-75 Ton (SAHL)
Figure 9, p. 34, Table 4, p. 34, Table 5,
and Table 6, p. 35,
Unit dimensions, 90-130 Ton Figure 12, p. 40
Typical unit and operation weights Table 12, p. 42
Center-of-Gravity illustration and related
dimensional data
Figure 13, p. 41
Evaporative Condenser
Unit dimensions, 20-89 Ton
(SEH_, SFH_, SLH_, SSH_, and SXH_)
Figure 10, p. 36, Table 7, p. 36,
Table 8, p. 37, and Table 9, p. 39
Typical unit and operation weights
(a)
(a) Weights shown represent approximate operating weights. Actual weights are stamped on the unit nameplate.
Table 13, p. 43
Center-of-Gravity illustration and related
dimensional data
Figure 13, p. 41
